Overview

Specifications

Engine
Model	YANMAR 3TNV80F
Rated power	15.2kw
RPM	2500 r/min
Displacement	1.267 L
No. of cylinder	3
Main Performance
Swing Speed (r/min)	10.5
Traveling Speed (km/H)	2.0/3.8km/h
Grade ability (%)	58%
Max. Bucket Digging Force (kN)	24.5
Arm Digging Force (kN)	14.8
Bucket Digging Force (kN)	9
Ground Pressure (Kpa)	31
Hydraulic System
Hydraulic system working pressure (Mpa)	22
Machine Weight (KG)	2650/2700
Max. flow (L/min)	67.2
Fuel Tank Capacity (L)	35
Hydraulic Tank Capacity (L)	42
Overall Dimensions
Overall Length (mm)	4159
Overall Width (mm)	1500
Overall Height (mm)	2500
Mini Ground clearance	320
Track width (mm)	1550
Axle base(Track length on ground)(mm)	2040
Track Gauge(mm)	1250
Swing radius at tail (mm)	775
Swing radius at front (mm)	2096
Counterweight ground clearance(mm)	535
Turntable width (mm)	1550
Track shoe width (mm)	250
Operation parameters
Bucket Capacity (m³)	0.08
Max. Digging Radius (mm)	4610
Max. Digging Depth (mm)	2485
Max. Digging Height (mm)	4132
Max. Dumping Height (mm)	2742
Max. vertical digging depth (mm)	2240
