Specifications

Engine
Model	Laidong KM385B 18.1kW/2200rpm KUBOTA D1105 14.2kw/2200rpm
Type	Direct injection, water cooled, natural intake
No. of cylinder	3
Main Performance
Swing Speed (r/min)	10-12
Traveling Speed (km/H)	2.8
Grade ability (%)	70(35°)
Traveling Tracking Force (kN)	15
Bucket Digging Force (kN)	11.5
Arm Digging Force (kN)	9.3
Hydraulic System
Hydraulic system working pressure (Mpa)	16
Hydraulic Pump (Gear Pump)	TJHD
Hydraulic pump flow (L/min)	2×22+8.8
Swing Motor	Eaton
Traveling Motor	Eaton
Fuel Tank Capacity (L)	26
Hydraulic Tank Capacity (L)	27
Overall Dimensions
Overall Length (mm)	3800
Overall Width (mm)	1050
Overall Height (mm)	2280
Ground clearance (mm)	485
Track length (mm)	1630
Track width (mm)	230
Undercarriage width (mm)	1050
Undercarriage ground clearance (mm)	235
Dozer Blade (mm)	1050×240
Operation parameters
Operation Weight (KG)	1800
Bucket Capacity (m³)	0.1
Max. Digging Radius (mm)	3860
Max. Digging Depth (mm)	2050
Max. Digging Height (mm)	3370
Max. Dumping Height (mm)	2390
Max. Dozer Cutting (mm)	270
Max. Dozer Lifting (mm)	235
Boom Deflexion (Left/Right) (°)	75/45
Tail Swing Radius (mm)	1125
Front Min. Swing Radius (mm)	1720
