Overview

Specifications

Engine
Model	Kubota D1703 18.5KW/2200rpm
Rated power	18.5kw
RPM	2200 r/min
Displacement	1.647 L
No. of cylinder	3
Main Performance
Swing Speed (r/min)	0-11
Traveling Speed (km/H)	4.4/2.4km/h
Grade ability (%)	58%
Max. Bucket Digging Force (kN)	30.4
Arm Digging Force (kN)	30.4
Arm Digging Force (kN)	18.2
Ground Pressure (Kpa)	32
Hydraulic System
Hydraulic system working pressure (Mpa)	22.5
Machine Weight (KG)	3810
Boom Length (mm)	2535
Arm Length (mm)	1400
Fuel Tank Capacity (L)	42
Hydraulic Tank Capacity (L)	48.5
Engine oil capacity (L)	7
Carrier roller(each side)	1
Supporting roller(each side)	4
Overall Dimensions
Overall Length (mm)	4915
Overall Width (mm)	1720
Overall Height (mm)	2525
Mini Ground clearance	295
Track width (mm)	300
Axle base(Track length on ground)(mm)	1670
Track Gauge(mm)	1420
Swing radius at tail (mm)	860
Swing radius at front (mm)	2538
Height of blade (mm)	350
Operation parameters
Bucket Capacity (m³)	0.12
Max. Digging Radius (mm)	5480
Max. Digging Depth (mm)	3208
Max. Digging Height (mm)	4800
Max. Dumping Height (mm)	3406
Max. vertical digging depth (mm)	3208
