| A.Total length | 3945mm |
| B.Total length without bucket | 2980mm |
| C.Bucket pivot point(to center of axle) | 450mm |
| D.Wheel base | 1930mm |
| E.Rear overhang | 430mm |
| F.Height with cab lowered | 1995mm |
| J.Total working height with bucket | 5280mm |
| K.Maximum height of bucket pivot point | 4537mm |
| L1.Load-over height telescopic arm retracted | 4165mm |
| L.Load-over height telescopic arm extended | 4300mm |
| M1.Dumping height telescopic arm retracted | 2355mm |
| M.Dumping height telescopic arm extended | 3570mm |
N.Reach(at M)
| 475mm |
| O.Digging depth | 95mm |
| P.Total width | 1564mm |
| Q.Track width | 1245mm |
| S.Ground clearance | 295mm |
T.Maximum radius
| 3550mm |
| U.Radius on the outer edge | 2695mm |
| V.Inner radius | 950mm |
| X.Rollback angle at max.lift height | 52° |
| Y.Dumping angle | 31° |
| Z.Rollback angle on ground | 44° |
