| Rated load | kg | 1550 |
| Max load | kg | 1650 |
| Tipping Load | kg | 28 |
| Bucket Capacity | m3 | 0.6 |
| Operating Weight | kg | 3900 |
| Maximum Breakout Force | kg | 30 |
| Fuel tank capacity | kg | 32 |
| Diesel Tank | L | 58 |
| Hydraulic Tank | L
| 5335 |
| A. Max.imum overall height | mm | 4153 |
| B.Height to hinge pin at maximum lift | mm | 3300 |
| C. Height to top of cab | mm | 2100 |
| D. Clearance bucket bottom to ground | mm | 3136 |
| E.Length without bucket | mm | 2915 |
| F. Length with bucket | mm | 3786 |
| G. Dump angle (full lift height) | ° | 40 |
| H. Dump height at maximum lift and dump | mm | 2615 |
| K. Bucket rollback at ground level | ° | 26 |
| L. Full rotation angle of bucket at the highest point | ° | 84 |
| M. Wheelbase | mm | 1640 |
| O. Angle of departure | ° | 31 |
| P. Ground clearance | mm | 216 |
| R. Front turning radius without bucket | mm | 1466 |
| S. Front turning radius with buckett | mm | 2274 |
| T. Rear turning radius | mm | 1809 |
| U. Bumper overhang behind Rear Axle | mm | 885 |
| U. Bumper overhang behind Rear Axle | mm | 885 |
